11.3-inch TFT LCD Display Module 540×1400 MIPI Interface IPS Wide Viewing Angle LCD Screen
  • Naam
  • Naam
  • Naam

11.3-inch TFT LCD Display Module 540×1400 MIPI Interface IPS Wide Viewing Angle LCD Screen

MOQ: 200 stuks
Prijs: $24.86-30.99/pieces
Standard Packaging: 28*40*15
Delivery Period: 14-60 dagen
Betalingswijze: T/T
Supply Capacity: 10000 stuks
Detailinformatie
Productomschrijving
Beoordelingen & Recensies
Detailinformatie
Plaats van herkomst
Guangdong, China
Merknaam
YZY
Certificering
CE, ROHS
Modelnummer
YVO113FHD-X01
Productomschrijving
11.3 Inch TFT LCD Display Module 540×1400 MIPI Interface IPS Wide Viewing Angle LCD Screen
High-performance 11.3-inch TFT LCD module with 540×1440 resolution, MIPI 4-lane interface, 600cd/m² high brightness, IPS full viewing angle and wide temperature range, specially designed for industrial control, automotive display, smart home, commercial display and embedded display applications.
Product Overview
This 11.3-inch TFT LCD module adopts a-Si TFT active matrix technology, supporting 16.7M full colors and stable image performance. It uses standard MIPI interface, 600cd/m² high brightness, IPS full viewing angle and thin border design. With wide operating temperature from -30℃ to 80℃ and high reliability, it is an ideal display solution for industrial equipment, automotive electronics, smart home panels, commercial devices and IoT intelligent terminals.
Technical Specifications
Display Type 11.3 Inch TFT-LCD, LCM
Model Number YVO113FHD-X01
Resolution 540(RGB) × 1440 Pixels
Display Mode IPS, RGB Vertical Stripe
Display Colors 16.7M Colors
Panel Type IPS, Full Viewing Angle
Interface MIPI 4-Lane
Brightness 600 cd/m² (Typical)
Viewing Angle 85/85/85/85° (Typical)
Backlight White LED, 30000 Hours Life
Outline Dimension 96.80(H) × 252.8(V) × 4.5(D) mm
Active Area 91.368(H) × 243.648(V) mm
Pixel Pitch 0.0365×0.1095 mm
Surface Treatment IPS Fine Sand Haze 15%
Color Gamut NTSC 75% (Typical)
Contrast Ratio 1200 (Typical)
Response Time 30ms (Typical)
Operating Temperature -30℃ ~ +80℃
Storage Temperature -30℃ ~ +80℃
Compliance RoHS Compliant
Key Features
  • 11.3-inch TFT LCD with 540×1440 high resolution and 16.7M true colors
  • IPS full viewing angle technology for clear display from all directions
  • 600cd/m² high brightness for excellent readability in strong light environments
  • MIPI 4-lane interface for stable and high-speed signal transmission
  • White LED backlight with long service life up to 30000 hours
  • IPS fine sand surface treatment for better visual experience
  • Thin border and compact structure for easy integration into end products
  • Wide temperature range for stable operation in harsh industrial environments
  • High reliability passed high/low temperature and humidity reliability tests
  • RoHS compliant, fully meet international environmental protection standards
  • Support OEM & ODM customization for FPC, pin definition and structure
Applications
  • Automotive central control displays, air conditioner screens and interior displays
  • Industrial control panels, PLC equipment and industrial human-machine interaction
  • Smart home control panels and smart home appliance displays
  • Commercial POS machines, self-service equipment and advertising displays
  • IoT intelligent terminals and industrial display equipment
  • Handheld industrial instruments and testing devices
  • Medical device displays and electronic monitoring equipment
  • Custom LCD display solutions for various OEM/ODM industrial projects
Product Documentation
11.3-inch TFT LCD Display Module 540×1400 MIPI Interface IPS Wide Viewing Angle LCD Screen 0
Product Image
11.3-inch TFT LCD Display Module 540×1400 MIPI Interface IPS Wide Viewing Angle LCD Screen 1
Application examples in industrial and consumer devices
11.3-inch TFT LCD Display Module 540×1400 MIPI Interface IPS Wide Viewing Angle LCD Screen 2
Partner companies and collaborative projects
11.3-inch TFT LCD Display Module 540×1400 MIPI Interface IPS Wide Viewing Angle LCD Screen 3
Manufacturing facility and quality control environment
11.3-inch TFT LCD Display Module 540×1400 MIPI Interface IPS Wide Viewing Angle LCD Screen 4
Shipping methods and delivery information
Company Profile
Shenzhen Yingzhanying Technology Co., Ltd. (YZY) was founded in January 2018 and is located in Shenzhen, China—a global hub of the electronics industry. Its predecessor is Shenzhen Shengyuan Optoelectronics Co., Ltd., established in 2013. The company specializes in custom services, R&D, sales and after-sales services in the optoelectronic display industry.
Products include Liquid Crystal Display (LCD) modules (LCM), touch modules, LCD panels, FPC (Flexible Printed Circuit) boards and various optoelectronic materials. These are widely used in industrial control, medical equipment, handheld devices, instruments and meters, automotive electronics, digital wearables, household appliances, and financial services.
Frequently Asked Questions
How do you control product quality?
Each product undergoes strict testing before shipping following MIL-STD-105E sampling plan and multiple reliability tests including high/low temperature storage, high temperature & high humidity operation and image sticking test.
Do you supply samples?
Yes, we provide samples for customer evaluation and functional testing.
What is the delivery time?
Typically 7 working days after payment confirmation for standard orders. Custom orders may require additional lead time.
What is the minimum order quantity?
200 piece minimum order quantity for sample orders, with flexible MOQ for bulk production.
What if we receive missing or defective items?
Contact us immediately for investigation and prompt resolution. We offer replacement or refund for confirmed quality issues.
What are your main products?
Comprehensive range including LCD modules, LCM, touch modules, LCD panels, FPC boards and optoelectronic materials for industrial, medical, automotive, smart home and consumer electronics applications.
What payment methods do you accept?
We accept T/T (Telegraphic Transfer) payments, Western Union, and PayPal for small orders.
What shipping methods do you offer?
DHL, FedEx, UPS and China Post shipping services available. Express delivery is available for urgent orders.
