YBC101UMH-Q1(MPI1010) 10.1-inch HDMI capacitive touch display for Raspberry Pi 5, long screen with resolution of 1520x720

The YQX6-101 is a high-quality 10.1-inch IPS LCD display featuring 1024*600 resolution and 5-point capacitive touch screen, designed for versatile applications including Raspberry Pi projects, computer monitors, and gaming consoles.

1. Raspberry Pi Exclusive - Simple Connection: We provide matching adapters and brackets, enabling the Raspberry Pi to be installed closely side-by-side with the screen. The integrated design is simple and elegant, far surpassing the clutter of traditional separate connections.
2. Long-shaped IPS Hard Screen: Features a 10.1-inch long-barrel-shaped IPS screen, naturally suitable for vertically displaying codes, browsing long web pages, monitoring data, or serving as a secondary timeline for video editing, thus saving valuable desktop depth space.
3. USB No-driver 5-Point Touch Screen: Capacitive touch technology supports up to 5-point touch. Can be directly plugged in and used on mainstream systems such as Windows, Raspberry Pi OS, and Ubuntu, without the need for additional drivers. The interaction experience is direct and efficient.
4. Extreme Compatibility: Not only is it the best companion for Raspberry Pi, but it is also an ideal secondary screen for PCs. Also supports game consoles such as Switch and Xbox. One screen covers various scenarios including development, office work, and entertainment.
5. Simple Interface & Convenient Operation: Just one HDMI cable is needed to transmit the picture, and one USB cable is used for power supply and to enable touch control. The body is equipped with physical menu buttons, allowing for easy adjustment of display parameters such as brightness and contrast.

1. Step 1: Download the Latest Official Image
   • Raspbian: Download from raspberrypi.org/downloads/raspbian/ (username: pi, password: raspberry)
   • Ubuntu Mate: Download from ubuntu-mate.org/download/ (set username/password after boot)
   • Kali Linux: Download from offensive-security.com/kali-linux-arm-images/ (username: kali, password: kali)
   • Retropie: Download from retropie.org.uk/download/ (username: pi, password: raspberry)
2. Step 2: Burn the Official Image
   • Download and install required tools:
     • SD Formatter: sdcard.org/downloads/formatter_4/
     • Win32DiskImager: sourceforge.net/projects/win32diskimager/
   • Format the SD card using SD Formatter with quick format option
   • Burn the image using Win32DiskImager (process takes approximately 10 minutes)
3. Step 3: Insert the SD Card

   After burning completes, insert the SD card into the SD card slot on the back of the Raspberry Pi.

4. Step 4: Run the System

   Connect the HDMI interface and TOUCH interface of the display to the Raspberry Pi, then turn on the Raspberry Pi power supply to enable normal display and touch functionality.

This product can be used as an HDMI touch display for Windows computers. Simply connect the HDMI interface and the TOUCH interface of this product to the corresponding interfaces of your computer, and you can directly display and use touch functionality.
