5 Inch 480x854 Resolution MIPI Interface In-cell TFT LCD Touch Screen Display Module
  • name

5 Inch 480x854 Resolution MIPI Interface In-cell TFT LCD Touch Screen Display Module

MOQ: 100 pcs
Price: $1.99-199.99 Piece
Payment Method: T/T
Supply Capacity: Up to 1,000 pcs/day
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
YZY
Certification
CE，RoHS
Model Number
YVT0050JNM-X1
Screen Size:
5.0 Inch
Resolution:
480 × 854
Module Size:
82 × 130 × 3.13 Mm
Active Area:
61.78 × 109.91 Mm
Brightness:
400 Cd/m²
Support Color:
16.7M Colors
Display Interface:
MIPI Interface
Touch Interface:
I2C
Viewing Angle:
80/80/80/80 Typ.
Operating Temperature:
-20℃ To +70℃
Storage Temperature:
-30℃ To +80℃
Operating Life Time:
10,000 Hours
Highlight:

5 inch MIPI TFT LCD display

,

480x854 resolution touch screen module

,

In-cell TFT LCD touch screen

Product Description
5 Inch In-cell TFT LCD Touch Screen 480x854 MIPI Interface 400 Nits Full Lamination Display
Product Overview

This 5-inch In-cell TFT LCD touch screen features 480×854 resolution, MIPI interface, and normally black transmissive display mode. It utilizes ST7102 driver IC and supports 16.7M colors, free viewing direction, and 800:1 typical contrast ratio. The module incorporates SCA full lamination, AGC cover glass, AF coating, ≥6H surface hardness, and TP I2C signal pins including SDA, SCL, INT, and RESET. With dimensions of 82 × 130 × 3.13 mm, it is ideal for handheld terminals, smart control devices, portable instruments, and customized embedded touch display applications. Customization is available for brightness, cover glass, touch solution, FPC structure, interface, and other specifications based on project requirements.

Key Features
  • 5-inch In-cell TFT LCD touch screen with 480×854 resolution
  • MIPI interface for embedded smart terminal integration
  • In-cell touch structure with TP I2C signal pins
  • ST7102 driver IC with 16.7M color display performance
  • SCA full lamination design for integrated touch display assembly
  • AGC cover glass with AF coating and ≥6H surface hardness
  • Free viewing direction with 80/80/80/80 typical viewing angle
  • Customization support for brightness, cover glass, FPC and interface design
Product Display
5 Inch 480x854 Resolution MIPI Interface In-cell TFT LCD Touch Screen Display Module 0
5 inch TFT LCD display module front view
5 Inch 480x854 Resolution MIPI Interface In-cell TFT LCD Touch Screen Display Module 1
Additional display module view
Application Scenarios
  • Handheld smart terminals requiring 5-inch In-cell touch display
  • Portable POS devices and mobile payment equipment screens
  • Industrial handheld controllers with MIPI display interface
  • Smart home control panels and compact touch control devices
  • Medical handheld instruments and portable testing equipment
  • Custom embedded touch display projects using 5-inch portrait LCD modules
Company Capabilities
5 Inch 480x854 Resolution MIPI Interface In-cell TFT LCD Touch Screen Display Module 2
Professional testing and storage facilities
5 Inch 480x854 Resolution MIPI Interface In-cell TFT LCD Touch Screen Display Module 3
Extensive inventory management systems
5 Inch 480x854 Resolution MIPI Interface In-cell TFT LCD Touch Screen Display Module 4
Quality control and testing processes
Extensive Inventory: Over 1,000,000 self-owned stock items including Raspberry Pi boards, LCD monitors, touchscreens, cases, cables, and accessories from leading brands.
Competitive Pricing: Significant price advantages to reduce purchasing costs and save valuable time. We wholesale and distribute new, original, well-known brand electronic components worldwide.
Quality Assurance: Equipped with internationally advanced electronic component testing equipment and scientific storage systems to ensure consistent product quality.
Expert Team: Elite professionals with over 20 years of industry experience and deep understanding of international market trends.
Frequently Asked Questions
How do you control product quality?

Each item undergoes strict testing before shipping to ensure reliability and performance.

Do you supply samples?

Yes, we provide samples for evaluation.

What is the delivery time?

Typically 7 working days after payment confirmation.

What is the minimum order quantity?

1 piece minimum order quantity.

What if we receive missing or defective items?

Please contact us immediately, and we will investigate to provide the best solution promptly.

What are your main products?

Comprehensive range including Raspberry Pi development boards, LCD monitors, touch screens, housings, cables, accessories, plus development boards and accessories from NVIDIA, micro:bit, Arduino, BeagleBone Black and other leading brands.

What payment methods do you accept?

We accept T/T (Telegraphic Transfer) payments.

What shipping methods do you offer?

DHL and China Post shipping services available.

5 Inch 480x854 Resolution MIPI Interface In-cell TFT LCD Touch Screen Display Module 5
Additional company capabilities
Tags:

TFT LCD TouchScreen,

TFT Touch Display,

Custom TFT Display
