| Brand Name: | YZY |
| Model Number: | YVT0970NPM-S1 |
| MOQ: | 500 pcs |
| Price: | $16.37-22/pieces |
| Payment Terms: | T/T |
768×1024 | MIPI Interface | ‑20~+70℃ Wide Temperature Industrial LCD Panel
Product Front View
Product Back View
Product Side View
YVT0970NPM‑S1 is a 9.7‑inch Normally‑Black transmissive a‑Si TFT‑LCD module, vertical‑stripe RGB pixel arrangement, resolution 768(H) × 1024(V), supports 16.7M rich colors with MIPI high‑speed interface. Built‑in 42‑piece white LED backlight.
Industrial‑grade performance: operating temperature ‑20℃ ~ +70℃, storage temperature ‑30℃ ~ +80℃. Passed strict vibration, shock, high‑low temperature reliability tests. Supports tearing‑effect signal synchronization, perfect for tablet, handheld device and embedded industrial projects.
| Model | YVT0970NPM‑S1 |
| Screen Size | 9.7 inch |
| Resolution | 768(H) × 1024(V) |
| Module Size | 164.2(W) × 210.2(H) × 5.0(T) mm |
| Active Area | 147.456(W) × 196.608(H) mm |
| Display Color | 16.7M Colors |
| LCD Type | Normally Black, Transmissive a‑Si TFT |
| Backlight | 42‑pcs White LED, Typ 140mA, 30000hrs lifetime |
| Interface | MIPI |
| Operating Temp | ‑20℃ ~ +70℃ |
| Storage Temp | ‑30℃ ~ +80℃ |
Mechanical Outline Drawing
Module size
YVT0970NPM‑S1 9.7‑inch MIPI TFT‑LCD screen is widely used for handheld industrial terminals, tablet devices, portable testing equipment, medical handheld instruments, smart display terminals, embedded control equipment, HMI human‑machine interface and other vertical embedded display solutions.
Welcome to send inquiry for YVT0970NPM‑S1. We are able to offer complete datasheet, sample testing service, bulk order quotation and customized display solution.
Please send over your technical requirements via platform message. Our professional sales team will reply you promptly during working days.
