YBR026GEP-Q1 2.6-inch Arduino Display LCD Module with 320*240 Resolution, 8-bit Parallel Bus, and 65K Color Display for UNO/Mega2560
  • name

YBR026GEP-Q1 2.6-inch Arduino Display LCD Module with 320*240 Resolution, 8-bit Parallel Bus, and 65K Color Display for UNO/Mega2560

MOQ: 500
Price: $4.8-5.3/pieces(MAR2601）
Standard Packaging: 16*15*6(cm)/36g
Delivery Period: 30-45days
Payment Method: T/T
Supply Capacity: 50K/Month
Detail Information
Product Description
Ratings & Reviews
Detail Information
Place of Origin
China
Brand Name
YZY
Certification
CE/ROHS
Model Number
YBR026GEP-Q1
Type:
Arduino Display
Display Size:
2.6 Inch
Supplier Type:
Factory
Product Description
YBR026GEP-Q1 2.6-inch Arduino Display LCD Module
A 2.6-inch TFT LCD module with 320×240 resolution and 8-bit parallel bus, designed for Arduino UNO and Mega2560 development boards.
Product Overview
The Arduino UNO module is a 2.6-inch TFT LCD module with 320×240 resolution and 65K color display. It uses 8-bit parallel port communication with ILI9341 driver IC. The module includes an LCD display, 5V~3.3V level conversion circuit, and can be directly plugged into Arduino UNO and MEGA2560 development boards. It also supports SD card expansion functionality.
YBR026GEP-Q1 2.6-inch Arduino Display LCD Module with 320*240 Resolution, 8-bit Parallel Bus, and 65K Color Display for UNO/Mega2560 0
Product Features
  • Supports development boards such as Arduino UNO and Mega2560 for plug-in use without wiring
  • 320×240 resolution with clear display and touch function support
  • 16-bit RGB 65K color display for rich color reproduction
  • 8-bit parallel bus for faster refresh rates compared to serial SPI
  • On-board 5V/3.3V level shifting IC, compatible with 5V/3.3V operating voltage
  • Easy expansion with SD card slot
  • Comprehensive Arduino library with rich sample programs
  • Military-grade process standards for long-term stable operation
  • Underlying driver technical support provided
Technical Specifications
YBR026GEP-Q1 2.6-inch Arduino Display LCD Module with 320*240 Resolution, 8-bit Parallel Bus, and 65K Color Display for UNO/Mega2560 1
Interface Description
YBR026GEP-Q1 2.6-inch Arduino Display LCD Module with 320*240 Resolution, 8-bit Parallel Bus, and 65K Color Display for UNO/Mega2560 2 YBR026GEP-Q1 2.6-inch Arduino Display LCD Module with 320*240 Resolution, 8-bit Parallel Bus, and 65K Color Display for UNO/Mega2560 3
Connection to Arduino
YBR026GEP-Q1 2.6-inch Arduino Display LCD Module with 320*240 Resolution, 8-bit Parallel Bus, and 65K Color Display for UNO/Mega2560 4
Arduino UNO direct insertion connection
YBR026GEP-Q1 2.6-inch Arduino Display LCD Module with 320*240 Resolution, 8-bit Parallel Bus, and 65K Color Display for UNO/Mega2560 5
Arduino Mega2560 direct insertion connection
