1.3 Inch Round TFT LCD Module with 240x240 Resolution and GC9A01 Driver IC
  • name
  • name
  • name

1.3 Inch Round TFT LCD Module with 240x240 Resolution and GC9A01 Driver IC

MOQ: 5 pieces
Price: $3.47-4.99/pieces
Standard Packaging: 15*15*8
Delivery Period: 14-60 days
Payment Method: T/T
Supply Capacity: 10000 pieces
Detail Information
Product Description
Ratings & Reviews
Detail Information
Place of Origin
Guangdong, China
Brand Name
YZY
Certification
CE, ROHS
Model Number
YXR22-13
Highlight:

1.3 Inch Round TFT LCD Module

,

240x240 Resolution LCD Display Module

,

GC9A01 Driver IC a-Si TFT LCD Module

Product Description
YZY 1.3 Inch Round IPS LCD Display Module
High-performance 1.3-inch round TFT LCD display module with 240*240 resolution, GC9A01 driver IC, and 4SPI interface for smart wearables, IoT devices and industrial applications.
Product Overview
This circular a-Si TFT LCD module features 240(RGB)*240 high resolution with transmissive/normally black display mode and ALL VIEW viewing direction. Driven by GC9A01 IC with 4SPI interface, it supports white LED backlight and industrial-grade wide temperature range. With a slim 1.64mm profile and RoHS HSF compliance, it is ideal for smart watches, wearable devices, smart home control panels, and small-sized human-machine interface (HMI) systems.
Technical Specifications
Display Type1.3 Inch Round a-Si TFT LCD Module
Module NumberYXR22-13
LCD Type1.3 inch
Resolution240(RGB) * 240 Pixels
Technology Typea-Si TFT
Pixel ConfigurationR.G.B. Vertical Stripe
Display ModeTransmissive / Normally Black
Viewing DirectionALL VIEW
Driver ICGC9A01
Interface4SPI Interface (ZIF-0.5 PITCH 16PIN connector)
Number of Color262K
LCD Driver Voltage11V ±0.3V
Backlight TypeWhite LED
Operating Temperature-20℃ ~ +70℃
Storage Temperature-30℃ ~ +80℃
Outline Dimension35.60 * 38.10 * 1.64 mm (W * H * T)
Active Area (AA)32.4 * 32.4 mm
With / Without Touch screenWithout (optional touch version available)
Match Connector TypeZIF-0.5 PITCH 16PIN
Weight (g)TBD
ComplianceRoHS HSF
Unspecified Tolerances±0.20mm
All Radii (Without Dimension)R0.3mm
All Draft Angles1.5°
Key Features
  • 1.3-inch circular a-Si TFT LCD with 240*240 high resolution for sharp, clear 262K color display
  • Transmissive / Normally Black display mode with ALL VIEW viewing direction for wide-angle visibility
  • RGB vertical stripe pixel configuration for accurate color reproduction
  • GC9A01 driver IC with 4SPI interface for reliable and fast data transmission
  • White LED backlight for bright and uniform illumination
  • Industrial-grade wide temperature range (-20℃ to 70℃) suitable for harsh operating environments
  • Slim 1.64mm profile design for compact and space-saving device integration
  • Precision manufacturing with tight dimensional tolerance (±0.20mm) for consistent quality
  • RoHS HSF compliant, meeting international environmental protection standards
  • ZIF-0.5 PITCH 16PIN connector for easy and secure electrical connection
  • All radii without dimension set to R0.3mm and draft angles to 1.5° for optimized structural design
  • Flexible FPC design with 0.2mm thickness for reliable installation and wiring
Applications
  • Smart watches and fitness trackers with compact round display
  • Wearable medical devices and health monitoring equipment
  • Smart home control panels and IoT sensor displays
  • Industrial HMI systems and small-sized instrument panels
  • Portable consumer electronics and handheld devices
  • Automotive interior ambient lighting and small information displays
  • Custom electronic prototypes and DIY projects with circular display requirements
  • Smart wearable accessories and fashion tech products
Product Documentation
1.3 Inch Round TFT LCD Module with 240x240 Resolution and GC9A01 Driver IC 0
Technical drawing and dimensions
1.3 Inch Round TFT LCD Module with 240x240 Resolution and GC9A01 Driver IC 1
Application examples in industrial and consumer devices
1.3 Inch Round TFT LCD Module with 240x240 Resolution and GC9A01 Driver IC 2
Partner companies and collaborative projects
1.3 Inch Round TFT LCD Module with 240x240 Resolution and GC9A01 Driver IC 3
Manufacturing facility and quality control environment
1.3 Inch Round TFT LCD Module with 240x240 Resolution and GC9A01 Driver IC 4
Shipping methods and delivery information
Company Profile
Shenzhen Yingzhanying Technology Co., Ltd. (YZY) was founded in January 2018 and is located in Shenzhen, China--a global hub of the electronics industry. Its predecessor is Shenzhen Shengyuan Optoelectronics Co., Ltd., established in 2013. The company specializes in custom services, R&D, sales and after-sales services in the optoelectronic display industry.
Products include Liquid Crystal Display (LCD) modules (LCM), touch modules, LCD panels, FPC (Flexible Printed Circuit) boards and various optoelectronic materials. These are widely used in industrial control, medical equipment, handheld devices, instruments and meters, automotive electronics, digital wearables, household appliances, and financial services.
Frequently Asked Questions
How do you control product quality?
Each product undergoes strict testing before shipping following MIL-STD-105E sampling plan and multiple reliability tests including temperature cycling, vibration test and display performance validation.
Do you supply samples?
Yes, we provide samples for customer evaluation and functional testing.
What is the delivery time?
Typically 7 working days after payment confirmation for standard orders. Custom orders may require additional lead time.
What is the minimum order quantity?
1 piece minimum order quantity for sample orders, with flexible MOQ for bulk production.
What if we receive missing or defective items?
Contact us immediately for investigation and prompt resolution. We offer replacement or refund for confirmed quality issues.
What are your main products?
Comprehensive range including LCD modules, LCM, touch modules, LCD panels, FPC boards and optoelectronic materials for industrial, medical, automotive and consumer electronics applications.
What payment methods do you accept?
We accept T/T (Telegraphic Transfer) payments, Western Union, and PayPal for small orders.
What shipping methods do you offer?
DHL, FedEx, UPS and China Post shipping services available. Express delivery is available for urgent orders.
